Z-Axis Adjustment Stages
VTS-series
• The VTS series Z-axis adjustment platforms are designed with cross-roller bearings to provide excellent stability and parallelism when moving in the plane. Each Z-axis platform is equipped with fine adjustment knobs, providing precise height adjustment with each rotation.
• The VTS-1 platform has dimensions of 50mmx64mm and features 4 M4 x 0.7 threaded holes and 5 M6x1P threaded holes for component attachment. By utilizing an inclined plane for height adjustment, the VTS-1 achieves a 2:1 ratio between the length of the incline and the Z-axis height, resulting in a resolution of 5 micrometers.
• The VTS-3, VTS-4, and VTS-5 platforms utilize a lever principle to control the vertical movement of the Z-axis when adjusting the fine adjustment knobs horizontally.
• The VTS-3 platform measures 60mmx60mm and features 13 M6x1P threaded holes for component attachment. It also includes locking knobs for precise and secure platform locking, ensuring higher stability.
• The VTS-4 platform measures 60mmx60mm and features 8 M4 x 0.7 threaded holes, 6 M6x1P threaded holes, and a central M16x1P hole. This platform design allows for both horizontal adjustment and vertical lifting, with the ability to lock in position.
• The VTS-5 platform measures 42mmx42mm and features 12 M4 x 0.7 threaded holes and 4 M2x.0.4P threaded holes. It also offers the capability of locked horizontal adjustment and vertical lifting, making it the most precise and compact design within the Craftstar Z-axis platform series.
|
||
.jpg)
.jpg)
.jpg)
.jpg){kind=link}
| Specification |
|
Item Number:
|
M-VTS-1 | M-VTS-3 | M-VTS-4 | M-VTS-5 | |
|
Platform Size
|
50mm x 64mm | 60mmx60mm | 60mmx60mm | 42mmx42mm | |
|
Driver
|
5um Micrometer | 10um Micrometer | 10um Micrometer | 10um Micrometer | |
|
Travel
|
±3.5mm | ±6.5mm | ±4.0mm | ±2.0mm | |
|
Resolution
|
5um | ≒10um | ≒10um | ≒10um | |
|
Material
|
Aluminum 、Anodized Black | ||||
|
2D-Drawing
|
.jpg) |
|
|
|
|
