TCS60-05-series
• The TCS60 series platform employs a steel cross-roller bearing track design, characterized by high rigidity, high load capacity, low friction, and minimal operational noise. It is well-suited for applications requiring high-precision displacement. To cater to user convenience, we offer the option of two drive mechanisms: a 10um micrometer and a 100TPI precision screw.
• And the M16 tapped hole at the center of the stage can mount PH-XJ post holders.
| Specification |
| Platform Size | Driver | Travel |
Resolution |
Straightness | Material |
| 60 x 60mm | Micrometer / 100TPI Screws Center Driver | ±6.5mm | 10um | ±7.5um | Aluminum 、Anodized Black |
