TC60-05-series
• The TC60 series stage adopts a design with roller bearing linear steel rail tracks, which provides excellent stability and maintains consistent linear displacement. To ensure user convenience, we offer two driving options: micrometer and 100TPI precision screws for selection.
• The product surface is treated with a hard anodized finish, and each platform is equipped with precision positioning locks, allowing orthogonal errors between two assembled platforms to be within 2mrad.
Note:The product will be discontinued when sold out.
Note:Recommend replacing with the TCS-series or TCSJ-series Crossed Roller Guide Stage featuring steel crossed roller guides for higher precision and reduced friction.
| Specification |
| Platform Size | Driver | Travel | Resolution | Straightness | Material |
| 60 x 60mm | Micrometer / 100TPI Screws Center Driver | ±6.5mm | 10um | ±15um | Aluminum 、Anodized Black |
| Products | Part Number/Description | Delivery | Price | Qty. | Add to Cart |
