TP-series

• TP-2 features two adjustment dimensions (Pitch, Yaw) to cater to optical component angle adjustments. The θx travel can be adjusted up to 6 degrees, and depending on the model, the θy travel can be adjusted from 6 degrees to 12 degrees.

• TP-1 platform dimensions are 72 x 127mm and are equipped with M6 holes on the surface for component attachment. TP-2 platform dimensions are 76 x 76mm and have both M6 and M4 threaded holes on the surface, providing a wider range of options for component attachment. Both models are available with two driving options: fine-pitch rack and 100 TPI precision screws.

*Both TP-1 and TP-1A products are currently available as existing inventory versions (V1). Once the existing inventory is depleted, they will be replaced with the new version (V2). For detailed product specifications, please refer to the specification drawings.*

Specification

Item number	TP-1	TP-1A	TP-2	TP-2A
Platform Size	72 x 127mm	72 x 127mm	76 x 76mm	76 x 76mm
Pitch	6°	6°	6°	6°
Roll	12°	12°	6°	6°
Actuators	Micrometer	100TPI Screw	Micrometer	100TPI Screw
2D-Drawing (V1)
2D-Drawing (V2)			-	-
